Introduction to 59U:

Single end face/unbalanced type/any direction of rotation/in accordance with EN12756 (DIN24960)

This series of mechanical seals has a multi-spring structure, small axial size, compact structure, and reliable sealing. It is widely used in oil, water, organic solvents and other corrosive media.

Operating parameters:

Specification: 14 ~ 100mm | Pressure: ≤1.7Mpa | Temperature: -20℃~ 200℃ | Linear velocity: ≤25m/s | Axial movement: ±0.5mm

Material combination:

Sealing end face: graphite, silicon carbide, tungsten carbide, alumina

Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, PTFE

Metal components: stainless steel, SUS304, SUS316L
