103 Introduction:

This series is a typical single-spring mechanical seal with a single-end face parallel spring transmission. The seal conforms to DIN24960, TISO3069, and GB6556 standards. It is a widely used standard unbalanced mechanical seal. Various materials and end face combinations are allowed to meet Extensive industrial requirements.

Operating parameters:

Pressure in the sealed chamber: ≤1MPa

Temperature in the sealed chamber: -45℃~180c ("O" ring)-25℃~220C (V" ring)

Linear speed: ≤20m/Sec

Medium: water, oil, corrosive medium below medium
