Introduction to MG1:

Single end face/unbalanced type/any direction of rotation/rubber bellows

The MG1 series is the most commonly used seal. Rubber bellows cannot withstand torsional stress. It is exquisitely designed and has multiple functions, such as pushing the moving ring, which is both a secondary seal and a driving part of the moving ring. The moving ring is driven by the L ring and the spring without bonding. The moving ring can be replaced with various materials. It can be used in wastewater and sewage containing particles.

Operating parameters:

Specification: 10~ 110mm Pressure: ≤1.2Mpa | Temperature: -20℃~ 120℃ | Linear velocity: ≤10m/s | Axial movement: ±0.5mm

Material combination:

Sealing end face: graphite, silicon carbide, tungsten carbide, alumina

Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber

Metal components: stainless steel
